Nr13 Certified Custom High Pressure Hot Water Storage Tank / Stainless Steel

Package Size1200.00cm * 600.00cm * 600.00cm Package Gross Weight4000.000kg The products are designed and manufactured ba

Send inquiry

Basic Info.

Model NO.	C-10/6.55
Function	Storage Pressure Vessel
Application	Liquid
Material	Stainless Steel
Pressure	1.6MPa≤p<10.0MPa
Storage Medium	Moncombustible/Nontoxic
Pressure Level	Medium Pressure (1.6MPa≤p<10.0MPa)
Condition	New
Corrosion Allowance	0mm
Installation Method	Vertical
Material Spec.	304
Design Pressure	7.2MPa
Test Pressure	10.1MPa
Design Standard	ASME
Transport Package	Iron Frame
Specification	10m³
Trademark	TK
Origin	China
HS Code	7311001000
Production Capacity	20

Packaging & Delivery

Package Size1200.00cm * 600.00cm * 600.00cm Package Gross Weight4000.000kg

Product Description

The products are designed and manufactured based on ASME VIII-1 code, meet the requirements of ASME, PED, AS1210 and other standards, as well as DOSH, CRN, EAC, MOM and other certification modes for you to choose. If you have any customized needs on the pressure vessel, you can contact us.
Zhejiang tank pressure vessel Co., Ltd. is a manufacturer specializing in the production of customized pressure vessels, we have ASME U and UM stamp authorization, and has obtained ISO9001-2015 quality system certification and PED Module H and Module H1 certificates issued by LRQA.

Standards or specifications that our products can comply with:

CODE:ASME SECT.VIII DIV.1 2021 EDITION

Code Certification:ASME U

Operating Pressure : 6.55MPa

Design Pressure : 7.2MPa

Temperature: 250ºC

Minimum design metal temperature(MDMT) at MAWP:-20ºC at 7.2MPa

Hydrostatic test pressure:10.1MPa at 0-48ºC

Medium name:Water

Corrosion allowance:0mm

Gross volume:10m³

Empty weight:13481kg

Product category	Design Code	Certifications
Air Receiver	ASME VIII-1/GB150	ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Liquid Receiver	ASME VIII-1/GB150	ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Separator	ASME VIII-1/GB150	ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Adsorption Tank	ASME VIII-1/GB150	ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Heat Exchangers	ASME VIII-1/GB150/GB151	ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
